|  • 2-stage active LNA
• Dielectric patch antenna
• Low noise and drop-out rate
• Linear regulator
• Low-loss RG/174 coaxial cable with double shielding
• Aluminum base
• Receiving frequency: L1 band (1575.42MHz)
• Output impedance: 50Ω
• Polarization: right hand circular (RHC)
• Bandwidth: 10dB/MHz at -3dB point
• VSWR: 1.5 typical at 1,575MHz
• Elevated angle coverage: 5 to 90°
• Az bearing coverage: 360°
• BPF: 10MHz B/W at -3dB
• Overall gain: 28dB
• Overall NF: 1.8dB
• K = 1 unconditionally stable
• Power input: 2.75 to 12V DC input, auto switching
• Power consumption: 11 to 13mA (maximum)
• Power input: reverse polarity short circuit shutdown
• Thermal over-current shutdown: >150°C
• Dimensions: 44 x 34 x 12mm
• Color: black
• Coaxial connector: BNC, SMA, SMB, MCX, MMCX, GT-5, andHirose
• Coaxial cable: RG-174U double-shielded 5m, low-loss0.7dB/m
• Operating temperature: -30 to 85°C
• Storage temperature: -40 to 90°C
• Optional OEM hardware:
o Open frame antenna with RF shield
o Open frame with 3 flanges and RF shield
o Antenna + aluminum base
|
